VINNAPAS® 192 (ULS)
VINNAPAS® 192 (ULS) is a self-crosslinking, aqueous polymer dispersion produced from the monomers vinyl acetate and ethylene for the Nonwovens market. The dispersion is produced without the use of plasticizers.
Properties
- VINNAPAS® 192 (ULS) offers a unique balance of high dry and wet strength, excellent absorbent properties, and imparts good hand feel.
- The dispersion has a low formaldehyde content of less than 100 ppm.
- Especially suited for use in feminine hygiene and related absorbent products, and pre-moistened wipes
Data sheets
General
VINNAPAS® 192 (ULS)can be applied by a number of different application methodes including saturation, spraying, foaming and print bonding.
It performs well on various fiber types including cellulose, rayon, glass and polyester. Temperatures above 150°C are necessary to achieve proper crosslinking.
Processing
Formulating recommendations include the addition of catalyst and a wetting surfactant. Catalysts should be added to the dispersion as a 10% solution under good agitation. Typical catalysts include ammonium chloride, citric acid and sodium bisulfate. A 1% catalyst level (solids on solids dispersion) is sufficient to achieve complete crosslinking of the polymer. Surfactants can also be added to
VINNAPAS® 192 (ULS) to improve penetration of the binder into the substrate and improve absorbency of the finished product. Effective surfactant levels are 0.5 to 1.0% on dispersion solids. The compatibility and efficacy has to be checked undertaking a storage test.
Polymer Dispersions
VINNAPAS® 192 (ULS) can be mixed with most VINNAPAS®- and VINNOL®-dispersions as well as with most anionic and/or nonionic aqueous polymer dispersions. However the compatibility of the mixture should be tested by undertaking a storage test.
Defoaming Agents
Suitable defoaming agents include 1)SILFOAM® SE9, 2) FOAMASTER® WO 2310, 3)AGITAN® 352 or 4)Surfynol® DF58. The compatibility and efficiency should be tested in any case. Thickening Agents We recommend, in particular, products with neutral pH, e.g. those based on cellulose derivatives, polyvinyl alcohol or polyurethane. Should alkali-swellable polyacrylic acid derivatives be used those need to be chosen that are effective with ammonia, in order not to interfere with the acid catalyzed cross-linking of VINNAPAS® 192 (ULS), like e.g. 5) Rheovis® AS 1125, 6)Viscalex® HV30, 7)ROHAGIT® SD15. Their compatibility and efficacy has to be checked.
1) SILFOAM® is a trademark of Wacker Chemie AG
2) FOAMASTER® is a trademark of BASF SE
3) AGITAN® is a trademark of MÜNZING Chemie GmbH
4) Surfynol® is a trademark of Evonik Resource Efficiency GmbH
5) RHEOVIS® is a trademark of BASF SE
6) VISCALEX® is a trademark of BASF SE
7) ROHAGIT® is a trademark of Synthomer PLC
If the product is used in applications other than those mentioned, the choice, processing and use of the product is the sole responsibility of the purchaser. All legal and other regulations must be complied with.
For questions concerning food contact status according the chapter 21 CFR (US FDA) and German BfR, please feel free to contact us.
Wacker Chemie AG Hanns-Seidel-Platz 4 D-81737 München GermanyPackaging
- 200 Kg Steel drum
- 220 Kg Steel drum
- 1 MT IBC
- 1.1 MT IBC
- 1 MT Returnable tote
- Flexi bag.
- Tank lorry
Storage
When the dispersion is stored in tanks, proper storage conditions must be maintained. The product has a shelf life of 9 months starting from the date of manufacture if stored in the original, unopened containers at temperatures between 5 and 30°C. Any longer periods for the maximum storage period that may be described in the Certificate of Analysis which accompanies each shipment of the product, take preference over this suggestion in which case the time period stated in the Certificate of Analysis shall be solely authoritative. Iron or galvanized-iron equipment and containers are not recommended because the dispersion is slightly acidic. Corrosion may result in discoloration of the dispersion or its blends when further processed. Therefore, the use of containers and equipment made of ceramics, rubberized or enameled materials, appropriately finished stainless steel, or plastic (e.g. rigid PVC, polyethylene or polyester resin) is recommended. As polymer dispersions may tend to superficial film formation, skins or lumps may form during storage or transportation. Filtration is therefore recommended prior to utilization of the product.
Preservation for Transport, Storage and further Processing
The product is adequately preserved during transportation and storage if kept in the original, unopened containers. However, if it is transferred to storage tanks, the dispersion should be protected against microbial attack by adding a suitable preservative package. Measures should also be taken to ensure cleanliness of the tanks and pipes. In unstirred tanks, a layer of preservative-containing water should be sprayed onto the surface of the dispersion to prevent the formation of unwanted skin and possible attack by microorganisms. The thickness of this water layer should be < 5 mm for low viscosity dispersions and up to 10-20 mm for high viscosity products. Proper procedures - periodic tank cleaning and sanitization - must be set up in order to prevent microbial attack. Contact your biocide representative/supplier for further plant hygiene recommendations. Measures should be taken to ensure that only clean air enters the tank when the dispersion is removed. Finished products manufactured from polymer dispersions usually also require preservation. The type and scope of preservation will depend on the raw materials used and the anticipated sources of contamination. The compatibility with other components and the efficacy of the preservative should always be tested in the respective formulation. Preservative manufacturers will be able to advise you about the type and dosage of preservative required. If the product is stored for a longer period, stirring is recomended before use.
